100538
Ships LTL freight · we'll confirm a delivery window
Low Price Guaranteed
Found it cheaper somewhere else? We'll match it. Call 800-493-7692 and we'll beat the deal.
Overview
The General Pump 100538 is a probe-style thermostat with a copper immersion bulb and a 60-inch insulated stainless-steel capillary rated to 4000 PSI, controlling water temperature from 86 to 250°F. It panel-mounts on a hot-water pressure washer and uses a dual-scale knob to set the target temperature; the immersion bulb reads the water directly for rapid response within ±5°F. The 16(4)A-380V electric rating handles burner control circuits, and the assembly is UL/CSA approved. Use it to replace a failed or drifting thermostat on a hot-water skid or burner system so the coil holds a consistent, safe outlet temperature.
What's included
- Probe-style sensing with copper immersion bulb
- Insulated stainless-steel capillary, 60 in. long, bulb rated to 4000 PSI
- Panel-mounted with dual-scale temperature knob
- Rapid response, accurate to ±5°F
- 86–250°F adjustment range
- 16(4)A-380V electric rating
- UL/CSA approved
Specifications
- Temperature Range
- 86 – 250°F
- Max PSI
- 4,000
- Capillary Length
- 60 in.
- Capillary Material
- Insulated stainless steel
- Bulb Material
- Copper
- Accuracy
- ±5°F
- Electric Rating
- 16(4)A – 380V
- Approvals
- UL/CSA
- Ship Weight
- 0.5 lbs.
