HR-SM18/SS Summit Manual 18” Hose Reel-450′ 3/8″ W/SS Pipe
Free shipping · built to order — call for the current lead time
Low Price Guaranteed
Found it cheaper somewhere else? We'll match it. Call 800-493-7692 and we'll beat the deal.
Overview
The HR-SM18/SS is a Summit manual 18" hose reel rated to 4000 PSI and 250°F, holding 450 feet of 3/8" hose or 325 feet of 1/2" hose. The stainless-steel discharge pipe is the upgrade over standard models — it shrugs off hot water and chemical exposure where painted steel pipes corrode first. The frame uses 16-gauge galvanized steel discs with rolled edges and a black corrosion-resistant powder coat, riding on maintenance-free sealed bearings with adjustable tension so the hose never free-rolls. Brass swivels with Viton seals come standard, inlet and outlet are 1/2" FPT, and pre-drilled mounting holes make truck, trailer, or wall installation straightforward. At 42 pounds, it's a solid fit for hot-water pressure washing and softwash rigs.
What's included
- Holds 450' of 3/8" hose or 325' of 1/2" hose
- 4000 PSI max working pressure, 250°F max temperature
- Heavy-duty stainless-steel hose discharge pipe
- 16-gauge galvanized steel discs with rolled edge and strengthening ridge
- Brass swivels with Viton seals, standard on all models
- Sealed maintenance-free bearings with adjustable tension to prevent free-rolling
- Bolt-on spring-loaded locks for easy field adjustment or replacement
- Pre-drilled mounting holes for truck, trailer, or wall installation; factory pressure tested
Specifications
- Hose Capacity
- 450' of 3/8" or 325' of 1/2" hose
- Max Working Pressure
- 4000 PSI
- Max Temperature
- 250°F
- Inlet
- 1/2" FPT
- Outlet
- 1/2" FPT
- Discharge Pipe
- Heavy-duty stainless steel
- Disc Material
- 16-gauge galvanized steel, rolled edge
- Swivel
- Brass with Viton seals
- Finish
- Black corrosion-resistant powder coat
- Reel Type
- Manual
- Weight
- 42 lbs
