Downstream Bypass 5 to 8 GPM 20% Chem Injector 1/2" QC

Overview

This is an assembled downstream chemical injector kit built for 5-8 GPM cold and hot water pressure washers. It uses a 20% fixed 2.1mm GP injector to pull liquid chlorine or other cleaning chemicals downstream of the pump, so chemical never runs through the pump. The 1/2" high-capacity flow path and plated quick couplers keep pressure loss minimal, letting you reach higher elevations and farther distances than a typical downstream injector. A plated ball-valve lets you switch between chemical draw and straight rinsing without restricting flow. It's an economical setup for heavy-use cleaning or entry-level soft-wash on your existing machine.

What's included

• Sized for 5-8 GPM cold and hot water pressure washers
• 20% fixed 2.1mm GP downstream injector
• Plated ball-valve to switch between chemical draw and rinse
• 1/2" plated quick-connect couplers for high-capacity flow
• Stainless steel inlet metering ball
• 48" chemical inlet suction hose with strainer
• 24" high-pressure bypass hose
• Zinc plated steel fittings; ships fully assembled

Specifications

Flow Range

5-8 GPM

Injector

20% Fixed 2.1mm GP

Couplers

1/2" Plated Quick-Connect

Ball Valve

Plated, SS Inlet Metering Ball

Chemical Inlet Hose

48" x 1/4", with strainer

Bypass Hose

24" High-Pressure

Fittings

Zinc Plated Steel
