HP5535 Pressure Washer Pump General Pump GP HD Belt Drive 3500 PSI- 5.6 GPM

Overview

The General Pump HP5535 is a belt-drive plunger pump rated for 3500 PSI and 5.6 GPM at 1450 RPM (4.5 GPM at 1125 RPM), built for continuous-duty commercial pressure washing. Running at belt-drive speeds instead of engine speed cuts heat and wear, and the construction backs it up: a forged brass manifold with an exclusive lifetime warranty, solid ceramic plungers with lubricated packings, oversized connecting rods, tapered roller bearings, and a large oil-bath crankcase with a sight gauge and dipstick. It carries a 24 mm (0.945 in.) shaft, 1/2"-14 BSPP-F inlet, 3/8"-19 BSPP-F discharge, and handles fluid up to 165°F — a solid choice for repowering a belt-drive machine or building a new skid. Install it with an unloader and a secondary safety relief valve.

What's included

• Continuous-duty HD belt-drive pump rated for 1125/1450 RPM operation
• Forged brass manifold with exclusive lifetime warranty
• Large-capacity anodized aluminum oil-bath crankcase
• Oversized HD connecting rods for maximum service life
• Heavy-duty tapered roller bearings minimize friction
• Solid ceramic plungers with lubricated packings
• Unitized stainless steel inlet and discharge valves
• Easy-view oil sight gauge and dipstick

Specifications

PSI

3500 (max discharge pressure)

GPM

5.6 @ 1450 RPM / 4.5 @ 1125 RPM

Max Pump Speed

1450 RPM

Max Inlet Pressure

125 PSI

Max Inlet Vacuum

9 ft. water (7.9 in. Hg)

Max Temperature

165°F

Inlet

1/2"-14 BSPP-F

Outlet

3/8"-19 BSPP-F

Shaft Diameter

24 mm (0.945 in.)

Plunger Bore

20 mm (0.787 in.)

Plunger Stroke

16 mm (0.630 in.)

Crankcase Oil Capacity

40.6 oz.

Weight

32 lbs.

Dimensions

12.2" x 9.2" x 6.9"
