Does this unit come with a battery?

Yes, it includes a marine-grade battery for the electric-start Honda GX690 engine. On 12V units, a 26 amp charging system keeps it topped off while the engine runs.

Can it be sold in California?

No, this configuration is not for sale in California because the on-board 12-gallon poly fuel tank is Non-CARB Evaporative Compliant. A California-compliant upgrade is available under the options.

How is it mounted and fed with water?

It's a skid built to mount and tank-feed on a trailer, deck, or truck bed. The low-profile aluminum/stainless frame has forklift pockets and lifting provisions, and the unit is fully self-contained with no external power required.

What are the frame dimensions?

The frame measures 50"L x 33"W x 50"H, a compact footprint designed for versatile installation on a trailer, deck, or truck bed.

American Pressure SystemsSKU: FS7040HA-12VHOT

Premium GX 690 Honda Electric Start 7 GPM- 4000 PSI High Output Hot Water

Name: Premium GX 690 Honda Electric Start 7 GPM- 4000 PSI High Output Hot Water
Brand: American Pressure Systems
SKU: FS7040HA-12VHOT
Price: 8999 USD
Availability: BackOrder

4000–4999 PSI7.0–7.9 GPMElectric

$8,99900

Free shipping · built to order — call for the current lead time

VisaMastercardAmexDiscoverPayPal

Available to order

Free shipping

Warranty

Financing available

Low Price Guaranteed

Found it cheaper somewhere else? We'll match it. Call 800-493-7692 and we'll beat the deal.

Overview

This is a self-contained hot-water pressure washer skid that puts out 4000 PSI at 7.0 GPM, driven by a Honda GX690 electric-start engine. It runs a General Pump on a reduced-RPM 3V-X belt drive, so the pump turns slower for longer service life, and heats through a schedule 80 coil fired by a Beckett burner with an adjustable thermostat. The frame is aluminum with a stainless steel sub-frame in a low-profile, compact footprint with forklift pockets and lifting provisions. It's built for contractors who need both high flow and high pressure with heat, and want a unit ready to mount and tank-feed on a trailer, deck, or truck bed.

What's included

Honda GX690 commercial electric-start engine, marine-grade battery included
General Pump on reduced-RPM 3V-X belt drive for long service life
Schedule 80 heating coil with stainless steel coil wrap and burner hood
Beckett burner with adjustable thermostat
Aluminum frame with stainless steel sub-frame, forklift pockets and lifting provisions
On-board 12-gallon poly fuel tank (Non-CARB; not for sale in California)
Fully self-contained, no external power required
Safety pressure relief valve plus engine and pump oil drains for easy maintenance

Heavy Duty

Best for: driveways, concrete, paint stripping, commercial degreasing

Specifications

Pressure (PSI): 4000 to 4999
Flow (GPM): 7.0 to 7.9
Engine: Electric, Honda
Horsepower: 15 to 20+
Drive: Belt
Pump: General Pump (reduced RPM); AR available
Water: Hot
Heating Coil: Schedule 80
Burner: Beckett, adjustable thermostat
Frame: Aluminum with stainless steel sub-frame
Fuel Tank: 12 gallon poly
Dimensions: 50"L x 33"W x 50"H
Charging System: 26 amp (12V units)
Warranty: 7 yr frame / 5 yr pump / 3 yr engine
