Premium IGX 800 Honda Electric Start 10 GPM- 3000 PSI High Output Hot Water Skid

Overview

This is a high-output hot water pressure washer skid rated at 3000 PSI and 10 GPM, built around a Honda IGX800 electric-start engine and a heavy-duty AR pump. It packs high flow and high pressure into a compact 50″L x 33″W x 50″H aluminum frame with a stainless steel sub-frame, forklift pockets, and lifting provisions, so it mounts and tank-feeds on a trailer, deck, or truck bed. A 3VX belt drive runs the pump at reduced RPM for longer service life, and a Beckett burner with a schedule 80 heating coil heats the water. Fully self-contained with an onboard 12-gallon fuel tank and marine-grade battery — no external power required. Built for contractors running demanding fleet-wash, degreasing, and heavy field cleaning.

What's included

• Honda IGX800 commercial electric-start engine, includes marine-grade battery
• Heavy-duty AR pump with reduced-RPM 3VX belt drive for long service life
• Compact 50″L x 33″W x 50″H low-profile frame with forklift pockets and lifting provisions
• Aluminum frame with stainless steel sub-frame
• Schedule 80 heating coil with stainless steel coil wrap, burner hood, and control panel
• Reliable Beckett burner with adjustable thermostat
• Onboard 12-gallon poly fuel tank, fully self-contained (no external power)
• Engine and pump oil drains plus safety pressure relief valve for easy maintenance

Specifications

Flow (GPM)

9.0+

Engine

Honda

Horsepower

15 to 20+

PSI

3000

Pump

AR (heavy-duty), 3VX belt drive

Burner

Beckett

Heating Coil

Schedule 80

Fuel Tank

12 gallon poly (onboard)

Dimensions

50″L x 33″W x 50″H

Frame

Aluminum with stainless steel sub-frame

Water Type

Hot Water

Charging System

20 amp (12V units)
