S/G1003HU-BLEACH

Overview

This is a Honda GX200-powered softwash skid built around the UDOR ZETA-42 PP diaphragm pump — a bleach pump engineered to run sodium hypochlorite. It puts out 10.4 GPM at 290 PSI through three GREENTECH diaphragms, all mounted on a compact aluminum skid at 31.3 lbs. The wet parts are chemical-resistant — anodized aluminum bodies with polypropylene heads and manifolds and stainless steel valves — so aggressive soft-wash chemicals won't chew up the pump. It's made for pro soft washers treating mold, bacteria, mildew, moss, fungus, and algae, where you need volume and reach at low pressure rather than high PSI.

What's included

• Honda GX200 engine on a compact aluminum skid
• UDOR ZETA-42 PP diaphragm pump built to pump sodium hypochlorite
• Chemical-resistant wet parts for aggressive soft-wash chemicals
• Three GREENTECH diaphragms
• 10.4 GPM at 290 PSI
• Bolt-on regulator to prevent leaks when adjusting the pressure knob
• Anodized aluminum bodies with polypropylene heads and stainless steel valves

Specifications

Flow (GPM)

9.0+

Engine

Honda

Drive

Gear Drive

Pump

UDOR ZETA-42 PP diaphragm (bleach pump)

Max Flow

10.4 GPM

Max Pressure

290 PSI

Max RPM

550

Diaphragms

3 GREENTECH

Frame Type

Aluminum skid

Inlet

1.25"

Outlet

1/2" x 2

Bypass

3/4"

Pump Material

Anodized aluminum bodies, polypropylene heads & manifolds, stainless steel valves

Diaphragm Material

GREENTECH

Oil Capacity

20 fl oz

Weight

31.3 lbs
